Diagrams

WIRING PARTS LIST

REF # PART # DESCRIPTION QUANTITY

1 12-804 Hour Meter 1

2* Lights Switch (Optional)

15-727 Switch Actuator, no light 1

15-782 Rocker Switch, Unlit 1

3* 34-201 Lights (Optional) 3

43-505 Lights Wire Harness 1

4 13-488 Ignition Switch 1

5 8975 Circuit Breaker, 30AMP 1

8977 Breaker Boot 1

6 45-119 Red Battery Cable 1

7 Battery (not included) 1

8 22-065 Black Battery Cable 1

9 13-750 Starter Solenoid w/ Connector 1

10 22-017 Starter Cable 1

11 43-024 18hp Briggs & Stratton 1

12 14-292 Seat Switch 1

13 50-359 Warning Indicator Lights 1

NS 45-042 Wire Harness 1

* 45-016 Light Kit

Smithco 45-204-C - Page 15
