Smithco 45-204-C - Page 71

A-13
Front Attachment
40" ANGLE PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-12-13-200 Hex Bolt,
1
/
2
- 13 x 2 4
HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 4
2 HMB-12-14 Machine Bushing,
1
/
2
x 14GA 8
3 80-006 Rod End 4
4 HNJ-12-20 Jam Nut,
1
/
2
- 20 4
5 27-073 Lift Rod 2
6 HB-38-16-125 Hex Bolt,
5
/
8
- 16 x 1
1
/
4
2
HNFL-38-16 Flange Whiz-Loc Nut,
5
/
8
- 16 2
7 45-181 Plow Mount 1
8 HCP-58-250 Clevis Pin,
5
/
8
x 2
1
/
2
2
HHP-18 Bridge Pin,
1
/
8
2
9 HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
2
HW-38 Flat Washer,
3
/
8
2
HWL-38 Lock Washer,
3
/
8
2
HN-38-16 Hex Nut,
3
/
8
- 16 2
10 27-017 Aluminum Sand Plow Blade 1
11 HB-58-11-300 Hex Bolt,
5
/
8
- 11 x 3 1
HNTL-58-11 Nylon Lock Nut,
5
/
8
- 11 1
12 42-495 Pivot Frame 1
13 13-167 Wear Blade 1
14 HB-38-16-100 Hex Bolt,
3
/
8
- 16 x 1 4
HNFL-38-16 Flange Whiz-Loc Nut,
3
/
8
- 16 4
15 HB-12-13-200 Hex Bolt,
1
/
2
- 13 x 2 2
HWL-12 Lock Washer,
1
/
2
2
16 HB-38-16-250 Hex Bolt,
3
/
8
- 16 x 2
1
/
2
2
HW-38 Flat Washer,
3
/
8
2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 4
17 45-231 Right Pusher Bar 1
18 45-106 Lift Assembly 1
18-221 Flange Bushing 2
19 27-073-02 Plow link, 3" 1
20 45-097 Lift Handle 1
21 HMB-34-14 Machine Bushing,
3
/
4
- 14GA 1
22 HP-18-150 Cotter Pin,
1
/
8
x 1
1
/
2
1
23 15-019 Grip 1
24 45-232 Left Pusher Bar 1
25 HHP-18 Bridge Pin,
1
/
8
2
26 HCP-12-150 Clevis Pin,
1
/
2
x 1
1
/
2
2
