Smoracy, LLC
Copyright 3/15 INSERT
MODELS 3680/2680 Beast
NOTICE Parts may not be exactly as shown.
STANDARD STYLE
LOCATION PART NUMBER DESCRIPTION
1 977-301087 Body Support Arm
2. 900-4908-78 Cutter Body Bolt
3 900-6907-68 Washer
4. 977-200835 Cutter Body
5. ** Splitter Tooth
6. 900-4901-66 Hex Nut
7. 900-4904-92 Cutter Body Nut
Torque Cutter Tooth Nut to 500 ft.-lbs. (678 Nm)
Torque Cutter Body Nuts to 700 ft.-lbs. (949 Nm)
** See Cutter Tooth Options
CUTTERHEAD COMPONENTS
