Copyright 12/14 97 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
LOCATION PART NUMBER DESCRIPTION
1. 977-301087 Cutterbody Support Arm
2. 900-4908-78 Cutterbody Bolt
3. 900-4904-92 1” Stover Lock Nut For Cutterbody Bolt
4. 900-6907-68 Steel Washers
5. 977-200527 Non-Replaceable Raker Cutterbody
6. 977-303056 Replaceable Raker Cutterbody Only (option)
7. 977-100056 Replaceable Raker 45
o
(option)
977-100057 Replaceable Raker Square Cut (option)
977-200122 Replaceable Raker Square Cut with four welds (option)
8. 900-4902-78 Replaceable Raker Bolt
9. 900-4901-66 7/8” Grade 8 Nut
10. * See Cutterteeth Section for descriptions
11. * See Cutterteeth Section for description
TEETH COMPONENTS
