Smoracy, LLC
Copyright 3/15 INSERT
MODELS 3680/2680 Beast
NOTICE Parts may not be exactly as shown.
STANDARD STYLE - 30 TOOTH
LOCATION PART NUMBER DESCRIPTION
1. 977-304031 1” Thick Cutter Body Support Arm
2. 900-4916-41 Cutter Body Bolt
3. 900-6907-68 Washer
4. 977-200800 Cutter Body
5. ** Cutter Tooth
6. 900-4901-66 Hex Nut
7. 900-4904-92 Cutter Body Nut
8. 977-301087 Cutter Body Support Arm
Torque Cutter Tooth Nut to 500 ft.-lbs (678 Nm)
Torque Cutter Body Nuts to 700 ft.-lbs. (949 Nm)
** See Cutter Tooth Options
CUTTERHEAD COMPONENTS
