Copyright 12/14 135 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 HYDRAULIC COMPONENTS
FOUR FUNCTION DIRECTIONAL CONTROL
VALVE
LOCATION PART NUMBER DESCRIPTION
22. Relief, Work Port, Model RC
23. Relief, Work Port, Model RCA
24. Relief, Anti-Cavitation Check, Work Port, Model CRA
25. Relief, Work Port, Model RCS
26. Relief, Main, Model WH
27. Relief, Main, Model WHA
28. Relief, Main, Model RP51
29. Plug, No Main Relief (NR)
30. 6770- Cover, Right
31. 8644- Cover, Right
32. 9310-006 Nut, Stud
33. 8072- Valve Section, 4 way, 3 position
34. 8072- Valve Section, 3 way, 3 position
43. 6825-007 Mid-Inlet Section, Split Flow, Top Inlet SAE 12
44. Handle Assembly, Vertical
46. Bracket, Standard Handle
47. K-6033-B Retainer, Seal, Standard
50. K-6056-B Boot Assembly, Spool Protective
