SMORACY BEAST 3680 - Page 154

Copyright 12/14 136 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
1
2
12
3
4
5
B
6
7
8
9
10
11
9
8
7
HYDRAULIC COMPONENTS
3 WAY - 3 POSITION VALVE
GRESEN YOKE LIFT
LOCATION PART NUMBER DESCRIPTION
1. K-6125-B Positioner, Spool, Standard
2. K-6030-C Check, Load
3. 1458-001 Plug, 3 way Conversion, SAE 10
4. 2707-001 Seal, O-ring, SAE10 Plug
5. K-6030-C Plug, Check (Load Check and Spring are not used)
6. K-6033-B Retainer Assembly
7. 6752-001 Retainer, Plate Washer
8. 3265-001 Washer, Back up
9. 7700-001 Seal, O-ring
10. 8072- Housing
11. 8083-001 Spool, 3 way
12. 6754-001 Plug, 3 way
