Smoracy, LLC

MODEL 3680 CONTROLS/START UP PROCEDURES

DISCHARGE BELT CONVEYOR MOTION (5)

Forward motion of the Discharge Belt Conveyor is accomplished by pushing the Discharge Belt Conveyor control

handle away from you. To stop the Discharge Belt Conveyor place the control handle in the middle or off position.

To reverse the Discharge Belt Conveyor pull the control handle toward you.

DISCHARGE BELT CONVEYOR FOLD (If Equipped) (7 & 8)

The Discharge Belt Conveyor must be stowed in the folded position when moving the machine. Before folding or

unfolding the Discharge Belt Conveyor, make sure the engine is at idle and everyone is clear from the Recycler

area. Remember, never slam the Discharge Belt Conveyor to a rest, always feather the controls to allow a smooth

stop.

Before unfolding, with the Discharge Belt Conveyor in the transport position, push the Discharge Belt Conveyor

fold control handles in one at a time for 4-5 seconds until the pressure gauge reaches 1800 PSI (124 bar). This will

purge the hydraulic system of any air.

To unfold the Discharge Belt Conveyor to its normal operating position pull the mid section Discharge Belt

Conveyor fold control handle until the mid section is fully extended. To unfold the upper section pull the upper

section Discharge Belt Conveyor fold control handle until the upper section is fully extended. Again remember, just

feather the controls, do not slam the Discharge Belt Conveyor to a stop.

Before folding, with the Discharge Belt Conveyor in the operating position, pull the Discharge Belt Conveyor fold

control handles out one at a time for 4-5 seconds until the pressure gauge reaches 1800 PSI (124 bar). This will

purge the hydraulic system of any air.

When folding the Discharge Belt Conveyor the upper section must be folded first, followed by the mid section.

Failure to follow these procedures may result in the belt becoming too tight and this could cause damage to the

machine. To fold the Discharge Belt Conveyor to its folded or transport position push the Discharge Belt Conveyor

upper section fold control handle away from you until the upper section Discharge Belt Conveyor is fully raised.

Then push the Discharge Belt Conveyor mid section fold control handle away from you until the Discharge Belt

Conveyor comes to rest on the Discharge Belt Conveyor support. Again, just feather the controls, do not slam the

Discharge Belt Conveyor to a stop. Slamming the Discharge Belt Conveyor could cause extensive damage to your

Recycler or cause serious injury or even death.

HYDRAULIC SHUT DOWN SWITCHES

There are four hydraulic shutdown switches located at the corners of the Recycler. When any of these switches

are pushed in, all hydraulic systems will stop. Be aware that the engine and Cutterhead will continue to run; these

switches only stop the hydraulic systems. All switches must be pulled back out for the hydraulic systems to work

again.

CAUTION

CONTROLS

SMORACY BEAST 3680 - Page 42
