MODEL 3680
CONTROLS
CONTROLS/START UP PROCEDURES
AVOID DAMAGE TO
DISCHARGE CONVEYOR
DO NOT move machine with Conveyor extended.
DO NOT fold or unfold Conveyor on uneven ground.
DO NOT cause abrupt stops when raising or lowering
Conveyor.
DO follow all operation, service and safety guidelines.
DO follow these steps to purge air from the hydraulic
system EVERY TIME the Conveyor is moved.
1. Place pressure gauge in diagnostic port of valve bank.
2. With Conveyor resting in fold or unfold position,
operate valve to position it further in that direction.
Hold valve position for 4 to 5 seconds until gauge
reads 2050 PSI.
3. Repeat these steps for second control valve.
4. Now you may proceed to raise or lower conveyor.
DO operate the Conveyor folding actions with engine at an idle.
DO fold Conveyor upper section first, then mid section.
DO NOT RUN OR
OPERATE MACHINE
WITH THE DOOR/
COMPARTMENT OPEN
Door/enclosure is a guard, you can
be injured if open during operation.
DANGER
