Smoracy, LLC
MODEL 3680
REPLACING CUTTERBODIES
CUTTERHEAD SECTION
Access to the Cutterbodies and inserts is below the raised Feedwheel. Refer to page 11 for proper
procedure to raise and safely secure the Feedwheel in position. Do not attempt any type of
maintenance without first disengaging clutch, turning off engine, waiting for the Cutterhead to come to
a complete stop, turning Battery Disconnect Switch off, and you must have the ignition key in
YOUR
possession.
CUTTERBODY REPLACEMENT
1. Disengage clutch, turn off engine, wait for the Cutterhead to come to a complete stop, turn Battery
Disconnect Switch off, and you must have the ignition key in
YOUR possession.
2. Block the Cutterhead so it will not turn on you when working on the Cutterbody.
3. Remove the 1” bolts and nuts that attach the Cutterbody, this will allow the Cutterbody to be taken
out of the Cutterhead.
4. Clean both holder arms to make sure Cutterbody clamps flat.
5. Insert new Cutterbody into the arms. Use only 1” bolts supplied by Smoracy, LLC to put back
together. Failure to do so, may cause premature failure to the Cutterbodies and will cause damage to
your machine. (Tighten 1” fine threaded bolts and nuts to 700 ft.-lbs. or 949 Nm).
Whenever servicing the head area, ALWAYS look for cracked welds and/or excessive wear on the
support arms. Cracks and worn Cutterbody Holder Arms could cause a Cutterbody to come off the
Cutterhead. This will cause major damage to your machine.
WARNING
ALWAYS use Smoracy, LLC replacement parts. Failure to do so may cause major damage to
your machine.
NOTICE
6. Check all Screen and Infeed Chain clearances. (3/4” or 19.1mm min. on infeed chain) (1/4”
or 6.4mm min. on anvil, concave gate, and screen.)
DANGER
