snom 760 User Manual
Setting up the Phone
Connecting the phone
The phone can be operated with Power over Ethernet (PoE) provided via the network cable or, if PoE is
not avaible in your network, with a 5V DC power adapter.
Optional
Optionnel
Opzionale
Opcional
Optional
Optionnel
Opzionale
Opcional
If no PoE available
Wenn PoE nicht verfügbar
S'il n'y a pas de PoE
Si no se dispone de PoE
Se non disponibile PoE
Not included in delivery
Nicht im Lieferumfang enthalten
Non inclus
Non incluido
Non incluso
USB 2.0
Type/Typ A
Optional
Optionnel
Opzionale
Opcional
• Plug the Ethernet (network) cable into the RJ45 connector labeled “NET”, and plug the other end
into the network side to establish a data link.
• The second RJ45 connector, labeled “PC”, is for daisy-chaining further Ethernet devices without
the need for a second Ethernet connection line.
• If PoE is not available, use a 5V DC power supply (not included in delivery).
Note: Use only a power supply expressly recommended by snom; other power supplies
may damage or destroy the phone, affect its behavior, or induce noise. I
Insert the plug of the power supply into the connector labeled
5V DC
and hook up the plug to
the wall outlet.
USB 2.0
Type/Typ A
