LowerControlBoxMod-SRxx70V2CEwith24VDCoption
Item SnorkelPart Description Vendor # Qty
1 13240-03 Loom- Inner ControlBoxMod24V 1
2 13240-04 Loom- LinkWire 4
3 10114 Contact- NO TelemecaniqueZBE-101 2
4 10118 Contact-NC TelemecaniqueZBE-102 1
5 1814 CableGland–M20Nylon 1
6 61003-005N CableTie –3.2X200,Black 6
7 12515 Washer – M12 Rubber 1
8 302-0097 Switch – Toggle,DPDTOn-On Honeywell 2NT1-3 1
9 13110 Decal–Battery/DieselSelect 1
1. Drill andfit thecableglandto thelowercontrolbox asbelow.
25mm
Drill 20mm
diahole
To Next Page
