2. Feed13240-03throughthecable gland andwire up the box asbelow.
Loom 13240-03connectsto S
DB
1, S
DB
2, S
DB
3, S
DB
5 and S
ES
C2-2
Link wires 13240-04connects: S
ES
C2-1 to S
BP
C4-4
S
BP
C3-4 to S
BP
C4-4
S
BP
C3-3 to S
BP
C4-3
S
BP
C3-4 to S
DB
4
3. Route thelooms up to theglandfollowing the existingwiringandcabletie to suit.
4. Fit the battery/dieselselectdecaltothecontrolbox.
1
2
3
4
5
6
S
DB
S
BP
C3
S
BP
C4
S
ES
C2
8
3
3
5
7
9
