Page 6 - 38 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
LOADER STOP BRACKET ASSEMBLY - 068190-000
ITEM PART NUMBER DESCRIPTION QTY
1 068191-000 Loader stop bracket weldment 1
2 068193-000 Slide pad - loader stop 2
3 03570-000 Retaining pin assy 1
4 014066-006 Screw 1/4 self tapping x 3/4 4
Table 6-19: UL25/32/40 loader stop bracket assembly components
Figure 6-19: UL25/32/40 loader stop bracket assembly illustration.
