Page 6 - 39UL25/UL32/UL40
ILLUSTRATED PARTS LIST
LOADER BAR ASSEMBLY - 068168-000
ITEM PART NUMBER DESCRIPTION QTY
1 068187-000 Loader bar weldment 1
2 068188-000 Slide pad 2
3 061694-005 Hose 2 5/8 OD x 2 ID x 5 2
4 062923-000 Loader hanger 1
5 015936-004 Bolt shoulder 3/8 x 1/2 2
6 011248-005 Nut hex ESNA 5/16 - 18 UNC 2
7 014066-006 Screw HWH SLFTP 1/4 - AB x 3/4 6
Table 6-20: UL25/32/40 loader bar assembly components
Figure 6-20: UL25/32/40 loader bar assembly illustration.
