Snorkel UL40 - Page 104

Page 6 - 40 UL25/UL32/UL40
OUTRIGGER ASSEMBLY
UL25/UL32 - 068157-001
ITEM PART NUMBER DESCRIPTION QTY
1 003471-000 Handle alarm 1
2 003508-000 Knob UL - Outrigger 1
3 003532-000 Pad assembly 1
4 026553-005 3/16” x 3/8” pop rivet 4
5 056059-045 Bolt, hexbolt DIN931 M8 x 45mm 4
6 056066-006 Nut nylock DIN985 M6 8.0 Zi 4
7 056066-008 Nut nylock DIN985 M8 8.0 Zi 4
9 056069-010 Washer, steelat washer DIN125 8
10 056069-016 Washer, steelat washer Din125A M16 Zinc 1
11 058491-050 Bolt, hexsetscrew DIN933 M6 4
12 062636-000 Jack screw 1
13 068102-001 Outrigger tube x 44 1
14 068148-000 Screw casting 1
15 508247-008 Washer, pennywasher, DIN9021, M8 8
16 056060-075 Bolt, hexbolt Din931 M10 x 75mm 4
17 970369 Bolt hexhead .313-18 1.00 GR5-5/1 4
18 056066-010 Nut, nylocknut Din985 M10 8.0 4
19 5569922 M8 spring washer 1
ILLUSTRATED PARTS LIST
Table 6-21: UL25/32 outrigger assembly components
