Page 6 - 3UL25/UL32/UL40
ILLUSTRATED PARTS LIST
GENERAL ASSEMBLY BREAKDOWN
UL25 - 514856-800 (AC)
514857-800 (DC)
UL32 - 514858-800 (AC)
514860-800 (DC)
UL40 - 514860-800 (AC)
514861-800 (DC)
ITEM PART NUMBER DESCRIPTION UL25 UL32 UL40
1
512805-100 Lift cylinder assembly 1
512789-100 Lift cylinder assembly 1
512806-100 Lift cylinder assembly 1
2
068050-001 2
nd
stage mast assembly 1
068050-002 2
nd
stage mast assembly 1
068050-003 2
nd
stage mast assembly 1
3
068056-001 3
rd
stage mast assembly 1
068056-002 3
rd
stage mast assembly 1
068056-003 3
rd
stage mast assembly 1
4
068061-001 4
th
stage mast assembly 1
068061-002 4
th
stage mast assembly 1
068061-003 4
th
stage mast assembly 1
5
068066-001 5
th
stage mast assembly 1
068066-002 5
th
stage mast assembly 1
068066-003 5
th
stage mast assembly 1
6
514600-001 6
th
stage mast assembly 1
514600-002 6
th
stage mast assembly 1
514600-003 6
th
stage mast assembly 1
7
068160-009 Cage support assembly 1
068160-010 Cage support assembly 1
068160-011 Cage support assembly 1
8 068218-000 Mast bearing 8 8 8
9 068217-000 Mast bearing 12 12 12
10 068216-000 Mast bearing 4 4 4
11 068122-000 Mast bearing 4 4 4
12 068121-000 Mast bearing 4 4 4
13 068120-000 Mast bearing 4 4 4
14 068119-000 Mast bearing 4 4 4
18 012553-005 Screw SOC HD 1/4 - 20 UNC x 5/8 21 21 21
19 012553-006 Screw SOC HD 1/4 - 20 UNC x 3/4 22 22 22
20 501258-020 Screw butt HD 3/8 - 16 x 5/8 8 8 8
21 062129-000 Strap retainer 5 5 5
22 011735-020 Roll pin 4 4 4
23 068143-000 Pin Leaf chain 2 2 2
