ILLUSTRATED PARTS LIST
ITEM PART NUMBER DESCRIPTION UL25 UL32 UL40
24 068141-000 Pin chain 2 2 2
25
510146-001 Cable connector gland 2 2 2
510147-001 Cable connector nut 2 2 2
27 056065-045 Bolt hexhd .500-13 1.75 GR5 4 4 4
28 056069-012 Washer, SteelFlatWasher M12 4 4 4
29 984519 Nut hex LKG .500-13 4 4 4
30 063926-007 Plug 2 2 2
31 011735-020 Roll pin 2 2 2
32 068140-000 Pin 2 2 2
40 068187-000 Loader assembly 1
41
068200-003 Tilt back assembly 1
068200-000 Tilt back assembly 1
068200-001 Tilt back assembly 1
42
062945-001 Retractile cord 1
062945-003 Retractile cord 1
062945-004 Retractile cord 1
43
062226-002 Cable storage tube 2
062226-003 Cable storage tube 2
062226-004 Cable storage tube 2
44
068157-001 Outrigger assembly 4
068157-001 Outrigger assembly 4
030838-007 Outrigger assembly 4
45
514735-000 Chassis weldment 1
514736-000 Chassis weldment 1
514737-000 Chassis weldment 1
46 514432-000 Motor cover 1 1 1
47 067995-000 Lifting alarm assembly 1 1 1
48 514817-000 Caster 2 2 2
49 068645-000 Axle shaft 1 1 1
50 514383-000 Wheel UL 10 x 2-1/2 2 2 2
51 068158-000 #1 Section slide 1 1 1
52 003570-000 Retaining pin 5 5 5
53 514471-000 Switch 4 4 4
54 514728-000 Stainless steel washer at 3/4" x 2" 2 2 2
55 068646-000 Roll pin 2 2 2
56 020398-024 Clamp 4 4 4
57 011868-032 Grommet strain relief 1 1 1
58 011868-019 Grommet snap 7/8 DIA 2 2 2
59 011252-010 Screw HHC 1/4 - 20 UNC x 1(1/4) 4 4 4
60 056060-030 Screw HHC 3/8 - 16 x 3/4 8 8 8
61 056058-020 Screw MRH 1/4 - 20 3 3 3
62 011240-004 Washer 1/4 STD at 20 20 20
