Page 6 - 8 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
AC POWER OPTION - 068008-011
ITEM PART NUMBER DESCRIPTION QTY
1
068115-001 Power unit
1
068115-011 Valve, load
068115-012 Pump
068115-013 Seal kit
068115-015 Motor
2 514458-000 Chassis harness, A.C. 1
3 514444-000 Control box 1
5 020809-001 Fitting, Tee
6MJ-6MB-6FJX
1
6 063965-003 Gage port 1
8 056069-008 Washer 8mm at 4
9 011240-004 Washer 1/4 at 4
10 011252-004 Screw HHC
1/4 - 20 (1/2)
4
11 056064-008 8 mm nut 4
13 013540-001 Wire nut 12-10 2
14 011868-019 Connection cable 1
Table 6-3: AC power option components and part numbers.
