Page 6 - 9UL25/UL32/UL40
ILLUSTRATED PARTS LIST
AC POWER OPTION - 068008-011
0
Brown Cable
Green Cable
Blue Cable
To mains
A.C. 110v connection type
White/Red Cable
Blue/Black Cable
Brown Cable
Green Cable
Blue Cable
To mains
A.C. 220v connection type
White Cable
Black Cable
Blue/Red Cable
2
Cable marker #4
Cable marker #3
Cable marker #4
Cable marker #0
Figure 6-3: AC power option illustration.
