Page 6 - 12 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
AC LOWER CONTROL BOX - 514444-000
ITEM PART NUMBER DESCRIPTION QTY
1 0120804 Push button; Schneider XB2BA3351C 1
2 0120803 Push button; Schneider XB2BA3341C 1
3 510542-000 Push button; Schneider XB2BA21C 1
4 510524-000 SW Twist release E/stop 1
5 512543-000 Keyswitch 1
6 513949-000 9 way chassis socket 1
7 514433-000 7 way chassis socket 1
8 514435-000 5 way chassis socket 1
9 502588-000 Alarm, ECCO beeping 6-28 VDC 1
10 510156-000 9 way panel plug 1
11 510157-000 12 way panel plug 1
12 505082-014 M5 x 14 skt button cap screw DIN9427 4
13 514442-001 Overlay 1
14 514439-000 UL AC lower control box weldment 1
15 514467-000 AC120 controller 1
16 514440-000 UL AC control box panel 1
17 514005-000 PSU 230 V AC to 12 V DC 7.5 A 1
18 029868-007 Circuit breaker 15 A 1
19 056064-006 M6 nylock nut 4
20 058502-025 M6 x 25 S.H.C.S. 2
21 501253-012 M6 x 12 Button HD. screw - 12.9 2
22 512368-000 Din rail (62mm) 1
23 514470-000 AC contactor 1
24 067155-001 Battery holder 3
25 026551-004 Pop-rivet 1/8” 6
26 510147-000 Cable gland M20 2
27 510146-000 Cable gland nut M20 2
28 056066-004 M4 nylock nut - 8 2
29 058500-012 M4 x 12 socket HD cap screw - 12.9 2
30 508077-000 3 - core cable 2.5mmCSA H07RN - F 2.5m
31 510167-000 8 A Diode 1
32 514642-000 Socket 4-way panel mount 1
33 512366-000 4-way panel plug 1
34 509755-000 Mate - n - lock SCKT contact 22
35 510145-000 Mate - n - lock pin contact 4
Table 6-5: AC Lower control box components.
