Page 6 - 18 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
2
nd
STAGE MAST ASSEMBLY
UL25 - 068050-001
UL32 - 068050-002
UL40 - 068050-003
ITEM PART NUMBER DESCRIPTION QTY
1
068055-001 2
nd
Stage mast assy UL25 1
068055-002 2
nd
Stage mast assy UL32 1
068055-003 2
nd
Stage mast assy UL40 1
2 068053-000 #2 Section slide 1
3 011703-016 Screw socket hex set 1/4 - 20 UNC x 1 2
Table 6-8: 2
nd
stage mast assembly components.
Figure 6-8: 2
nd
stage mast assembly illustration.
