Page 6 - 20 UL25/UL32/UL40
4
th
STAGE MAST ASSEMBLY
UL25 - 068061-001
UL32 - 068061-002
UL40 - 068061-003
ITEM PART NUMBER DESCRIPTION QTY
1
068064-001 4
th
stage mast assy UL25 1
068064-002 4
th
stage mast assy UL32 1
068064-003 4
th
stage mast assy UL40 1
2
062168-111 Chain 2
062168-137 Chain 2
062168-163 Chain 2
3 068138-000 Shaft 2
4 011753-020 Shaft 2
5 068146-000 Pin 2
6 062753-000 Strap assy 1
8 068065-000 #4 section slide 1
9 012553-008 Screw socket HD cap 1/4 - 20 UNC x 1 2
10 062642-016 Bearing 2
11 068136-000 Sheave 2
ILLUSTRATED PARTS LIST
Table 6-10: 4
th
stage mast assembly components.
