Page 6 - 22 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
5
th
STAGE MAST ASSEMBLY
UL25 - 068066-001
UL32 - 068066-002
UL40 - 068066-003
ITEM PART NUMBER DESCRIPTION QTY
1
068069-001 5
th
stage mast assy UL25 1
068069-002 5
th
stage mast assy UL32 1
068069-003 5
th
stage mast assy UL40 1
2
062167-141 Chain 2
062167-173 Chain 2
062167-205 Chain 2
3 068138-001 Shaft 1
4 068135-000 Sheave, 5 stage top 1
5 068140-000 Pin 2
6 062753-000 Strap assy 1
8 011751-004 Pin, cotter 1/16 x 1/2 4
9 011252-016 Screw HHC 1/4 - 20 x 2 2
10 011240-004 Washer 1/4 STD at 4
11 011248-004 Nut 1/4 - 20 UNC ESNA 2
12 068097-000 5
th
stage guide 1
Table 6-11: 5
th
stage mast assembly components.
