Page 6 - 24 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
6
th
STAGE MAST ASSEMBLY
UL25 - 514600-001
UL32 - 514600-002
UL40 - 514600-003
ITEM PART NUMBER DESCRIPTION QTY
1
514601-001 6
th
stage weldment UL25 1
514601-002 6
th
stage weldment UL32 1
514601-003 6
th
stage weldment UL40 1
2
062166-139 Chain 2
062166-171 Chain 2
062166-203 Chain 2
3 062753-000 Strap assy 1
5 068073-000 Chain block 1
6 011821-005 Screw Butt HD 1/4 - 20 UNC 4
7 068144 - 000 Clevis pin 6B 2
8 011735-005 Roll pin 1/8 DIA x 5/8 LG 2
9 068219-099 UHMW wear strip x 1(1/2) .25 ft
Table 6-12: 6
th
stage mast assembly components.
