Page 6 - 34 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
TILT BACK ASSEMBLY
UL32 - 068200-000
UL40 - 068200-001
ITEM PART NUMBER DESCRIPTION QTY
1 068180-000 Loader bar assembly 1
2 068190-000 Loader stop bracket assembly 1
3 068201-000 Tilt back weldment 32-40 1
4 062844-000 Tiltbar weldment 1
5 062846-001 Tube cylinder mount 1
6 068196-000 Inner tube 32 1
7 062884-002 Tube cylinder outer 1
8 062885-001 Fitting cylinder end 1
9 062886-000 Fitting cylinder end 1
10 062887-001 Pin cylinder mount 1
11 062891-001 Lanyard assembly 1
12 003570-000 Pin retaining 1
13 063650-003 Cylinder gas spring 1
14 062843-001 Grip 1
15 063926-004 Caplug 1
16 062888-003 Pin 3/4 x 2(1/2) 1
17 016590-001 Pipe .3/4 SCHD40ALUM 3/8 LG 2
18 514816-000 Caster 2
19 5592006 Ring retaining 2
21 504145-000 Split pin 3.2mm X 32 DIN 94 zinc plated 2
22 011256-008 1/2”- 13 UNC x 1” H.T. HEX Set 2
23 970269 Screw HHC 5/16 - 18 x 1 8
24 011256-022 Screw HHC 1/2 - 13 2(3/4) 2
25 986269 Flat washer .313 16
26 011248-008 Nut HEX ESNA 1/2-13 UNC 4
27 5560031 HEX lock nut .3125-18 UNC 8
28 016590-001 Pipe.3/4 SCHD40ALUMX3/8LG 2
Table 6-18a: UL32/40 tilt back assembly components.
