socomec Masterys BC User Manual

17
MASTERYS BC 100-120 kVA - Ref.: IOMMASBCXX07-EN 05
ENGLISH
2.6.5-4
2.6.5-3
2.6.5-2
2. UNPACKING AND INSTALLATION OF THE UNIT
F
ACS B.K. B.K.
XB1
B.K.
XB7
F1
VS1
NA1
COM1
XB8
NA2
COM2
XB9
F
N
230 V
BYPASS
B.K.
INPUT
XB4
XB2 XB3
BYPASS INPUT
XB5 XB6
N
F2
VS2
F
ACS B.K. B.K.
XB1
XB7
F1
NA1
COM1
XB8
NA2
B.K.
BYPASS
XB4
BYPASS INPUT
N
FN FN
VS2
Key
A Distribution panel
B Trip coil
X10 Mains terminal board
X40 Aux Mains terminal board
MAINS Mains switch
AUX MAINS Aux Mains switch
XB5 Aux Mains BKF connector
XB6 Mains BKF connector
AUX MAINS
AUX MAINS
protection
protection
MAINS
MAINS
protection
protection
Activating UPS protection on the mimic panel: access the
MAIN MENU > SETTINGS > UPS SETTINGS > BACKFEED
and set the parameter Backfeed Type to Separate Mains.
A UPS
AUX MAINS X40
BKF
XB6
XB5
MAINS
B
B
X10
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
• Separate Mains

socomec Masterys BC Specifications

General

Frequency	50/60 Hz
Power factor	0.9
Protection Degree	IP20
Input Voltage	400 V three-phase + N
Output Voltage	400 V three-phase + N
Efficiency	Up to 96%
Battery Type	VRLA
Operating Temperature	0 to +40 °C
Relative Humidity	0% to 95% (non-condensing)
Cooling	Forced air
Communication Interface	RS232, USB
Dimensions	Varies by model (e.g., 650 x 800 x 1200 mm for 20 kVA)
Weight	Varies by model (e.g., 300 kg for 20 kVA)
Topology	Double conversion
