socomec Masterys BC User Manual

5
ENGLISHENGLISH
MASTERYS BC 100-120 kVA - Ref.: IOMMASBCXX07-EN 05
1. SAFETY STANDARD
It is very dangerous to touch any part of the batteries as there is no insulation between the batteries and the mains
power source.
The product you have chosen is designed for commercial and industrial use only. If used for particular critical applications such as
life support systems, medical applications, commercial transportation, nuclear facilities or any other application or systems where
product failure is likely to cause substantial harm to people or property, products may have to be adapted. For such use please
contact SOCOMEC beforehand to check if these products meet the required levels of safety, performance, reliability, and comply
with applicable laws, regulations and specifi cations.
WARNING!
This is a product for commercial and industrial application in the second environment - installation restrictions or
additional measures may be needed to prevent disturbances.
1.2. DESCRIPTION OF SYMBOLS ON LABELS ATTACHED TO THE UNIT
All precautions and warnings on labels and plates inside and outside the equipment should be observed.
DANGER! HIGH VOLTAGE (BLACK/YELLOW)
GROUND TERMINAL
READ THE USER MANUAL BEFORE USING THE UNIT

socomec Masterys BC Specifications

General

Frequency	50/60 Hz
Power factor	0.9
Protection Degree	IP20
Input Voltage	400 V three-phase + N
Output Voltage	400 V three-phase + N
Efficiency	Up to 96%
Battery Type	VRLA
Operating Temperature	0 to +40 °C
Relative Humidity	0% to 95% (non-condensing)
Cooling	Forced air
Communication Interface	RS232, USB
Dimensions	Varies by model (e.g., 650 x 800 x 1200 mm for 20 kVA)
Weight	Varies by model (e.g., 300 kg for 20 kVA)
Topology	Double conversion
