MASTERYS BC 100-120 kVA - Ref.: IOMMASBCXX07-EN 05
The packaging guarantees the stability of the UPS during shipping and physical transfer. Carry the packaged unit as close as
possible to the installation site.
When moving the unit on even slightly sloping surfaces, use the blocking equipment and braking devices to ensure
the unit does not fall over.
2.1. SHIPPING AND MOVING
• The UPS must remain in a vertical position during all shipping and moving operations.
• Ensure the fl oor is strong enough to support the weight of the UPS and battery cabinet if used.
Avoid moving the unit by putting pressure on the front door.
The UPS MUST be handled carefully by at least two people.
CAUTION IF DAMAGED
If packaging is crushed, ripped or open such that the inner contents are revealed, the equipment should be kept in
an isolated area and inspected by a qualified person. If the packaging cannot be shipped the contents should be
collected promptly, kept apart, and the sender or recipient should be contacted.
All packaging must be recycled in compliance with existing legislation in the country where the system is installed.
2. UNPACKING AND INSTALLATION OF THE UNIT

socomec Masterys BC Specifications

General

Frequency	50/60 Hz
Power factor	0.9
Protection Degree	IP20
Input Voltage	400 V three-phase + N
Output Voltage	400 V three-phase + N
Efficiency	Up to 96%
Battery Type	VRLA
Operating Temperature	0 to +40 °C
Relative Humidity	0% to 95% (non-condensing)
Cooling	Forced air
Communication Interface	RS232, USB
Dimensions	Varies by model (e.g., 650 x 800 x 1200 mm for 20 kVA)
Weight	Varies by model (e.g., 300 kg for 20 kVA)
Topology	Double conversion
