MASTERYS BC 100-120 kVA - Ref.: IOMMASBCXX07-EN 05
5.3.11. REPORT ON USB
Reports containing UPS information can be downloaded onto a standard USB memory stick. The USB device must be formatted
with FAT32 fi le system.
There are two commands to download USB reports:
- User Report: this is a .txt fi le translated in the language set on the display. It contains information regarding the UPS, statistics,
counters and the history log.
- Service Reports: there are three fi les that can help troubleshooting for after sales service.
Step 1
Insert the USB stick into the UPS USB port placed on the inside of the UPS door.
Step 2
A menu appears with the USB services. Choose REPORT ON USB. Alternatively enter the menu: MAIN MENU > SERVICE >
REPORT ON USB. When on a parallel system the SYS unit has to be selected beforehand on the mimic panel page.
Step 3
Select the required report, press ENTER and follow the instructions displayed.
Step 4
Remove the USB stick when completed.
Step 5
The reports are saved in the folder \SOCOMEC\REPORTS.
5. HUMAN MACHINE INTERFACE

socomec Masterys BC Specifications

General

Frequency	50/60 Hz
Power factor	0.9
Protection Degree	IP20
Input Voltage	400 V three-phase + N
Output Voltage	400 V three-phase + N
Efficiency	Up to 96%
Battery Type	VRLA
Operating Temperature	0 to +40 °C
Relative Humidity	0% to 95% (non-condensing)
Cooling	Forced air
Communication Interface	RS232, USB
Dimensions	Varies by model (e.g., 650 x 800 x 1200 mm for 20 kVA)
Weight	Varies by model (e.g., 300 kg for 20 kVA)
Topology	Double conversion
