24 EN
MASTERYS GP4 60-160 kVA - Ref.: IOMMASGPXX07-EN 05
5.3 UPS switches
KEY
Q1
Input switch (MAINS)
Q4
Auxiliary mains Input switch (AUX MAINS)
Q5
Maintenance bypass switch
Q3
Output switch
A UPS connections
UPS In/Out
phase
Battery
type
Details
kVA
60-120 3/3 External
battery
Q1
Q4
Q5
Q3
A
160
Q1
Q4
Q5
Q3
A
