8.2 Menu architecture
MENU ITEMS
Stand alone UPS
[UPS]
Unit
[1] to [6]
UPS System
[SYS]
MONITORING
▶ ALARMS • • •
▶ STATUS • • •
▶ SYNOPTIC •
▶ UNIT • •
▶ SYSTEM • •
▶ UNITS OVERVIEW • •
EVENTS LOG • • •
MEASUREMENTS
▶ OUTPUT MEASUREMENTS • • •
▶ BATTERY MEASUREMENTS ^ ^ ^
▶ INPUT MEASUREMENTS • • •
▶ INVERTER MEASUREMENTS • •
▶ BYPASS MEASUREMENTS ^ ^ ^
CONTROLS
▶ UPS PROCEDURE
▶ START •
1
•
1
▶ STOP •
1
•
1
▶ ON MAINTENANCE BYPASS •
1
•
1
▶ MODE
▶ ECO MODE CONTROLS
▶ Eco Mode ON ^ ^
▶ Eco Mode OFF ^ ^
▶ ECO MODE SCHEDULE ^ ^
▶ ENERGY SAVER CONTROLS
▶ Energy Saver ON ^
▶ Energy Saver OFF ^
▶ BATTERY
▶ BATTERY CONTROL
▶ BATTERY TEST ^ ^ ^
▶ BATTERY SCHEDULE ^ ^ ^
▶ MAINTENANCE
▶ Alarms reset • • •
▶ Postpone maintenance alarm • • •
▶ LED test • • •
▶ User report • • •
