25EN
MASTERYS GP4 60-160 kVA - Ref.: IOMMASGPXX07-EN 05
5.4 Wiring diagram
KEY
X10 Input mains Q1 Input switch (MAINS)
X40 Aux mains Q4 Auxiliary mains Input switch (AUX MAINS)
X20 Battery Q5 Maintenance bypass switch
X50 Output Q3 Output switch
PE
60-160 kVA
External battery
