8.9 Additional user functions
8.9.1 Phase color modifi cation
• Enter MAIN MENU > USER PARAMETERS > PREFERENCES
For each phase is possible to select a specific colour in a set of colour range. Those colours are applying in the
measurements pages.
Colour Default colour
Yellow Phase 3
Orange
Red
Green
Light blue Phase 2
Dark blue
Purple Phase 1
Brown
Light grey
Dark grey
Black
The popup alarm appears in case of critical alarms. This function can be extended to preventive alarms by switching
“Preventive Popup Alarm” to ON.
