socomec MASTERYS GP4 - Internal Front View Details

26 EN
MASTERYS GP4 60-160 kVA - Ref.: IOMMASGPXX07-EN 05
5.5 Internal front view details
KEY
A1
Option slots 1
D
Ethernet network for service only
A2
Option slots 2
E
USB connector for service only
A3
Option slots 3
F
Backfeed card
B
Fuses
G
External Maintenance Bypass for UPS single
configuration only
1
C
230 V AC socket for service only
1. Connect a normally-closed early make contact from the external maintenance bypass switch.
E F
C
BA1A2
D
G
B
F A1 A2 A3
C
E
D
