6. CONNECTIONS
NOTE!
Before carrying out any operations on the unit read the 'Safety standards' chapter carefully.
WARNING!
Battery power terminals are supplied by external battery cabinet.
Before working on this circuit ensure that:
- all the external battery cabinet switches are in OFF position;
- the UPS is in maintenance bypass mode (refer to 'Operating modes' chapter)
Check for presence of voltage before operating.
Use cables with tin-plated eyelets for the connections.
• 60-120 kVA
1 2 3
OPEN
• 160 kVA
1 2 3
OPEN
