OFYS RT 1 - 3kVA - 551906A - SOCOMEC
13EN
2000VA
3000VA
1. AC input
2. Input circuit breaker
3. USB communication port
4. RS-232 communication port
5. SNMP intelligent slot (option)
6. ----
7. Output receptacles (max cables length = 3m)
6.1. Communication connection
To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication cable one end to the
USB/ RS-232 port and the other to the communication port of your PC. With the monitoring software installed, you can
schedule UPS shutdown/start-up and monitor UPS status through PC.
ATTENTION!
USB port and RS-232 port can’t work at the same time. Max cables length = 3m.
