SOFAR 1.1K~3KTL User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd
- 52 -
of this user manual, If it’s incorrect, change
it according to Section 6.3 (A) 10.Set Input
mode of this manual.
rong
mode
ID12
GFCIFault
GFCI Fault
If the fault occurs occasionally, the possible
cause is that the external circuits are
abnormal occasionally. inverter
automatically returns to normal operating
status after the fault is rectified.If the fault
occurs frequently and lasts a long
time,check whether the insulation
resistance between the PV array and
earth(ground) is too low, then check the
insulation conditions of PV cable.
ID14
HwBoostOCP
The input current
is too high , and
has happen
hardware
protection
Check whether the input current is higher
than the maximum input current of
inverters, then check the input wiring, if
both are correct, please contact technical
support.
ID15
HwAcOCP
The grid current is
too high , and has
happen hardware
protection
ID15-ID24 are internal faults of inverter,
turn OFF
the “DC switch”, wait for 5 minutes, then
turn ON the
“DC switch”. Check whether the fault is
rectified. If
no, please contact technical support.
ID16
AcRmsOCP
The grid current is
too high
ID17
HwADFaultIG
rid
The grid current
sampling error
ID18
HwADFaultD
CI
The DCI
sampling error
ID19
HwADFaultV
Grid
The grid voltage
sampling error
ID20
GFCIDeviceFa
ult
The GFCI
sampling error
ID21
MChip_Fault
The master chip
fault
ID22
HwAuxPower
Fault
The auxiliary
voltage error
ID23
BusVoltZeroFa
ult
The bus voltage
sampling error
ID24
IacRmsUnbala
nce
The Output
current is not
balanced
ID25
BusUVP
The bus voltage Is
too low
If the PV array configuration is correct (no
ID05 fault), the possible cause is that the
solar irradiance is too low. inverter
