Installation Requirements
13
Grounding Requirements
Grounding requirements are as follows:
 Ensure that the iSTAR Edge controller is properly connected to an earth ground at the
ground stud in the cabinet. Identified by symbol.)
Use 16 AWG or larger wire.
 Ensure that the shield wires for the readers, inputs, outputs, and AUX cables are grounded
to the nearest earth/ground connection at one end only of the cable.
 Disconnect the ground wire last to provide maximum protection to the equipment and
personnel.
NOTE
All cabling must be shielded.
