Overview and Introduction
6
All other LEDs only turn on when enclosure door is open.
Reset button.
Switches for serial termination of RM ports.
Switches for selection of relays for control by FAI.
Switch for FAI Latch.
Jumpers for relay wet/dry control.
Housing
Enclosure is similar to RM 4e enclosure.
Mountable in existing apC/L enclosure.
Compliance
FCC, CE, EN50133, UL60950 by CB Scheme (International Safety) & RoHS.
NOTE
For all compatible devices, see the iSTAR Edge Installation and Configuration Guide
(Doc. No. UM-236).
