Overview and Introduction
2
Overview and Introduction
Figure 1 shows a photograph of the iSTAR Edge with an optional PoE board and with an I8
and R8 mounted on the door.
Figure 1: iSTAR Edge Photo
The 4 reader model can be ordered with 2 RM-4s mounted on the door.
Figure 2 on page 3 shows an iSTAR Edge layout.
I8
R8
PoE
Ethernet
Tamper
Module
(I8 and R8 not included)
(Optional)
