Software House iSTAR Edge User Manual

Specifications
20
Switches and Jumpers
Rotary switch
There is an onboard 16 position rotary switch, SW1. Most of the positions are
used to control LCD diagnostics, and is similar to iSTAR eX.
Following is a reference table for iSTAR Edge rotary switch functions:
TABLE 10. iSTAR Edge Rotary Switch Functions
TABLE 9. Switches and Jumpers
Ref Type Description
SW1 Rotary Diagnostics, restore factory default and
other options.
SW7 Dual DIP Slide RS485-3 Termination
SW8 Dual DIP Slide RS485-2 Termination
SW9 Dual DIP Slide RS485-1 Termination
SW10 Push button Reset
J10 Jumper Relay Output 1 Source/Dry
J5 Jumper Relay Output 2 Source/Dry
J11 Jumper Relay Output 3 Source/Dry
J23 jumper Relay Output 4 Source/Dry
PoE Board - J2 Jumper Select PoE or PoE+
Position Description
0 ICU Block Off (Read/Write/Update) Display General Messages
1 Display card data from last card read, 7 second LCD display (slow mode)
2 Display card data from last card read, 2 second LCD display (fast mode)
3 Display supervised input changes, 2 second LCD display (slow mode)
4 Display supervised input changes, 1 second LCD display (fast mode)
5 Display manual output changes (include readers and R/8 boards), 2 second LCD display
(slow mode)
6 Display output changes (does not include readers and R/8 boards), 1 second LCD display
(fast mode)
7 Activate output test mode (include readers and R/8 boards_
8 Test Onboard Ethernet
9 Used to reset 24 V mode to 12 V mode (See Power chapter.)
A Not used
