iSTAR Edge Diagnostic Tests
35
Output Diagnostics
The iSTAR Edge provides three types of output tests:
Output Change Display (slow) – tests a specific output that is activated
manually by the technician
Output Change Display (fast) – activates and tests every output on the
system
Output Test Mode – activates and tests outputs one by one.
Output Change Display (Slow Mode)
The manual output test is an end-to-end test that displays information about
outputs activated manually by a technician. The outputs you are testing can be
attached to iSTAR Edge through readers and R/8 boards. Information displays
on the LED for two seconds.
To activate the output change display test, set rotary switch SW1 to the position
shown in Table 15.
Output Change Display (Fast Mode)
The output change display test is an end-to-end test that automatically activates
all outputs attached to iSTAR Edge. The outputs you are testing can be attached
to iSTAR Edge through readers and R/8 boards. Output information displays
on the LED for approximately one second. However, since outputs activate
faster than the one-second LCD display, the LCD does not display all output
information.
To activate the output change display test, set rotary switch SW1 to the position
shown in Table 16.
NOTE
Do not activate outputs on a live system!
TABLE 15. Manual Output Test Switch Settings
Switch
Position
Function
SW1 set to 5 Activate output change display for two seconds (slow mode)
TABLE 16. Output Change Display Settings
Switch
Position
Function
SW1 set to 6 Activate output change display test for one second (Fast
mode)
