Installation Requirements
8
Environmental
Requirements
Table 2 shows the iSTAR Edge environmental requirements.
Power Requirements
The standard iSTAR Edge uses a UL Listed 603 External Power Supply, such as
the Software House apS or uses a Power Over Ethernet (PoE or PoE+) injector.
To ensure adequate power, calculate the total power requirements of iSTAR
Edge and its related hardware, as follows.
Add the total current power for components in the system (modules, relays,
optional modules, readers, and wire resistance).
Tables 3 through 6 are provided to compute the current draw of components
attached to iSTAR Edge.
iSTAR Edge Components and Boards
Table 3 shows the power requirements of iSTAR Edge components and
attached boards.
a
RM-4 board has only been evaluated by UL with RM Series readers (RM 1,2,3)
b
RM-4E boards have only been evaluated by UL for use with RM-DCM-2 enclosure.
Depth 4.5" (11.4 cm)
TABLE 1. Cabinet Assembly Specifications
Item Specification
TABLE 2. Environmental Requirements
Status Range
Operation 32° F (0° C) to 120° F (48.9° C)
Storage 4° F (-20° C) to 158° F (70° C)
TABLE 3. Component and Board Power Requirements
Component/Board Current Draw at 12VDC
iSTAR Edge 400 mA with LCD - no load
RM-4 board
a
80 mA without LCD - no load
180 mA with LCD - no load
RM-4E board
b
125 mA - no load
I/8 board 125 mA - no load
R/8 board 150 mA - no active relays.
Add 20 mA for each active relay
