Pre-Installation Planning
5
Housing
Optional metal enclosure (12” x 12” x 4”) with lock and tamper switch is
slightly smaller than the RM-DCM-2 enclosure.
iSTAR Edge board is mountable in existing apC/L enclosures.
Compliance
FCC, CE, EN50133, IEC60950 by CB Scheme (International Safety) & RoHS.
PRE-INSTALLATION
PLANNING
Pre-installation involves the following:
1. Checking equipment (hardware, software, power supply, and wiring).
2. Checking power, wiring, equipment clearances, and code compliance at the
site.
3. Ensuring the proper tools are available.
Equipment Check
Verify that the contents of the shipped boxes match the packing lists. Contact
Software House if any items are missing or damaged.
The iSTAR Edge hardware does not include mounting hardware for an
installation. Mounting hardware depends upon the site and must be approved
by a structural engineer or other certified professional.
Software House recommends anchoring systems capable of sustaining a 20 lb.
load.
Site Check
Ensure that the mounting site is ready:
Mounting dimensions
• The can is 12” by 12” (30.48 x 30.48 cm)
• Upper mounting holes are 9" (22.86 cm) center to center.
• Bottom mounting holes are 10.5" (26.67 cm) below the upper mount
holes.
The site has been approved and all wiring complies with UL requirements
and other codes, as appropriate.
All preliminary site work is complete.
An appropriate power supply is accessible.
The site is clean and free of dust or other contaminants.
