Overview
4
I/O
8 General Purpose Inputs.
4 General Purpose Relays:
Dry or Wet contact controlled by a jumper for each relay.
4-pin connectors to support NO/NC and Dry/Wet configurations.
4- I8 and 4- R8 allowed to be configured on any of the three RS-485 ports.
Special purpose inputs:
Tamper (from enclosure door)
Main AC fail (from apS)
Low external battery (from apS))
PoE board present
Onboard battery low
USB Ports
A USB port is used to import encryption keys, in the same way as iSTAR
eX.
Communications
One 10/100 Ethernet port.
Full 256 bit (FIPS-197) AES encryption, as with iSTAR eX
Onboard controls
LCD with backlight for diagnostics.
Rotary switch for diagnostics, as with iSTAR eX.
LEDs for serial, Ethernet, power and relay state.
Two power LEDs: one super bright LED that is on when the enclosure
door is closed, and one green LED that is always on when main power is
present.
Relay activation LEDs are not affected by enclosure door.
All other LEDs are active only when the enclosure door is open.
Reset button.
Switches for serial termination of RM ports.
Jumpers for relay Wet/Dry control.
NOTE
The following two inputs to the host are determined by the firmware.
There is no actual wiring to the iSTAR Edge board.
