iSTAR Edge Diagnostic Tests
36
Output Test Mode
The output test mode activates all outputs, one by one. Test results are indicated
by the LED associated with each output.
To activate the output test, set switch SW1 to the position shown in Table 17.
Input Change Display
Mode
The input change display mode tests and displays information about inputs that
are activated manually. Inputs tested can be attached to iSTAR Edge through
the main board, RMs, and I/8 boards.
Information displays on the LED for either one second (Position 4, On) or two
seconds (Position 3, On).
To activate input change display tests, set the SW1 rotary switch to the positions
shown in Table 18.
Ethernet Port Test
The onboard Ethernet tests display diagnostic information about Ethernet
connections.
To test the Ethernet port, set switch SW1 to the position shown in Table 19.
TABLE 19. Ethernet Test Switch Settings
Observe the LCD display for test results.
TABLE 17. Output Test Switch Settings
Switch
Position
Function
SW1set to 7 Output Test Mode activates and tests all outputs one by one
TABLE 18. Input Test Switch Settings
Switch Position Function
SW1set to 3 Two-second LED input change display is on (slow
mode)
SW1set to 4 One-second LED input change display is on (fast
mode)
Switch
Position
Function
SW1set to 8 Tests the Ethernet Port
To Next Page
