Inverter programming and connections
1. Connect the cable between the master battery’s Main Control Module “INV 1” port and the inverter’s
“Battery CANBus” port (outdoor-rated models).
2. Program the inverter with the battery’s appropriate charge and discharge settings.
3. Enable “BMS Lithium Batt” and set this value to “00.”
4. (Optional) Turn on “BMS_Err_Stop” if you if you want the system to fault in case of battery
communications lost.
5. If communication still needs to be established, contact Renon to verify the unit has the latest firmware
and is configured for communication with Sol-Ark inverters.
