Pylontech – US3000C
Follow these instructions for setting up Pylontech batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by Pylontech for specifications
and settings to ensure optimal performance and safety. Visit the manufacturer’s website and consult the
relevant documentation below.
Pylontech documentation
You need a custom RJ45 cable for this setup.
Communications Installation and Setup Instructions
Custom RJ45 cable
1. Create a custom cable that connects battery pins 4 (solid blue), 5 (white-blue), and 6 (solid-green) to
inverter port pins 4, 5, and 6 respectively.
2. On indoor models, pin 6 (solid-green) needs to connect to pin two (2) on the inverter.
Battery-inverter communication connections
Wire color
Battery (A/CAN) port
Inverter port
Solid blue
4
4
White-blue
5
5
Solid green
6
2 (indoor only) or 6 (outdoor only)
