Homegrid – Stack’d
Follow these instructions for setting up Homegrid batteries and Sol-Ark inverters.
Be sure to consult the comprehensive technical documentation provided by Homegrid for specifications
and settings to ensure optimal performance and safety. Visit the manufacturer’s website and consult the
relevant documentation below.
Homegrid Stack’d documentation
You need a custom RJ45 cable for this setup.
Communications Installation and Setup Instructions
Custom RJ45 cable
1. Create a custom cable that connects pins 6, 7, and 8 ONLY (solid-orange, white-green, and solid-blue)
to the battery.
2. Pin 6 (solid-green) needs to connect to pin 6 on the inverter.
3. Pin 7 (white-brown) needs to connect to pin 5 on the inverter.
4. Pin 8 (solid-brown) needs to connect to pin 4 on the inverter.
On indoor models, pin 6 (solid-green) needs to connect to pin 2 on the inverter.
Battery-inverter communication connections
Wire color
Battery (CAN) port
Inverter port
Solid green
6
6
White-brown
7
5
Solid brown
8
4
